THE PLACE OF SPERM DNA FRAGMENTATION TESTING IN CURRENT DAY FERTILITY MANAGEMENT

Abstract

In this debate article, I am going to set out the case that sperm DNA fragmentation testing is essential in current day fertility management because:

  • Our current semen analysis testing is unfit for purpose
  • We need to take a fresh look at the ‘evidence’ against sperm DNA testing
  • Sperm DNA damage testing has strong associations with every fertility check point
  • Sperm DNA damage testing has strong associations with miscarriage
  • Sperm DNA testing can explain ‘unexplained’ infertility
  • There are reasons why sperm with poor DNA are successful in ICSI
  • There are no non-invasive sperm function tests that provide the same information.
  • We need to take a fresh look at the ‘evidence’ against sperm DNA testing

We have no reason to wait. There are benefits for clinics and couples alike.



1. We know traditional semen analysis tells us little-why do we keep using an inadequate batch of tests?

Male infertility is the commonest cause of infertility yet we keep sidetracking it. It contributes to nearly 50% of the ∼15% of couples of reproductive age. As a result of population aging and adverse changes in our lifestyle, infertility increases (with 4% more couples seeking ART per year) while we are only making a marginal improvement in pregnancy and birth rates after 30 years of trying. ART year on year (average live birth rate 21%, (6)). Why do we accept this as good enough for our patients? Why can we not improve? I believe that one major reason is that we do not understand the causes of male infertility at the molecular level. Furthermore, since the advent of intracytoplasmic sperm injection (ICSI), there has been no incentive to develop pharmaceutical therapies for male infertility. We believe we can get around the problem rather than solving it. But let us remember, in 30% of cases, women are subjected to invasive procedures for ICSI although they are fertile. Conventional semen analysis remains the only routine test to diagnose this condition although it cannot discriminate between the sperm of fertile and infertile men (10). This belief is reflected in the shifting values for normality (all ‘normal’ values are now lower) in the 5th edition of the WHO manual, (18) compared to previous WHO guidelines. Further, only 1% of sperm even reach the oocyte in vivo, so why would we expect an analysis of the widely ranging gross parameters of the whole ejaculate to give strong discriminatory information? That approach is simply not scientific. All that a semen analysis can do is identify men whose chance of achieving a natural pregnancy is very low i.e. they have few or no sperm…!

1.1. Why test sperm DNA?

Over the last decade, a plethora of studies (11) have confirmed that sperm DNA damage testing has strong associations with every early fertility check point. These include impaired fertilization, slow early embryo development, reduced implantation, miscarriage and, in animal studies, birth defects in the offspring. Childhood cancers have also been associated with oxidative damage to sperm DNA as a consequence of paternal smoking.

What couples would benefit from a sperm DNA test? To answer this question, we must first ask another. Why are we testing sperm DNA? The answer is so that we may guide couples with low damage to intrauterine insemination (IUI) or in vitro fertilization (IVF) and guide those couples with high DNA damage to ICSI (reasons why these sperm are successful after ICSI will be explained later). So, the only group who would not benefit from testing is that of couples with oligo-astheno-terato-zoospermia as there is no treatment other than ICSI for them.

As for all other categories of couples, sperm DNA testing will provide essential information on which clinics can guide couples to bespoke treatment for their particular needs. These include couples with unexplained infertility, men with normal semen by semen analysis prior to embarking on IVF, couples who have had unsuccessful IVF and couples who have had miscarriages.

1.2. What tests are currently available for sperm DNA damage?

For a sperm DNA test to be clinically useful it must have strong predictive capacity for pregnancy with little overlap between fertile and infertile samples. The four tests most often used today are the Comet assay, SCSA, the terminal transferase dUTP nick end labeling (TUNEL) assay, and the Sperm Chromatin Dispersion (SCD or Halo) test. Sperm DNA tests are all different. Just as apples are NOT oranges! Both are fruits but they are very different types of fruits. The current range of sperm DNA tests measure different aspects of DNA damage and have different sensitivities. That is why combining them in a meta- analysis (19)must be viewed with a little caution.

2. The Sperm chromatin structure assay

The SCSA is a fluorescence cell sorter test which measures the susceptibility of sperm DNA to denaturation after exposure to heat or acid conditions. A strength of SCSA is its ability to measure large numbers of cells rapidly. This gives it robust statistical power. It measures only single stranded fragments, and has demonstrated repeatedly strong associations between native, although not DGC, sperm and ART outcomes. In terms of sensitivity, it can detect sperm DNA damage in ∼20% of unexplained couples. However, the SCSA test has been tried and tested over many years and has a standardized protocol for all users. This has reduced inter-laboratory variation and allowed comparison of studies from different groups globally. The clinical threshold is a DNA fragmentation index (DFI) of 30%- that means 30% of the sperm have damage (with quantification into moderate or high damage) and 70% have no detectable damage. Couples with >30% damage are more likely to have success with ICSI than IVF.

3. The TUNEL assay

The TUNEL assay detects ‘nicks’ (free ends of DNA) by incorporating fluorescently stained nucleotides. This allows the detection of single and double stranded damage. The cells can be assessed either microscopically or by flow cytometric (FCM) analysis. A disadvantage of the assay is its many protocols, which makes comparison between laboratories almost impossible and explains its many clinical thresholds. Recently, Aitken’s group (2011) (14)has improved the TUNEL assay by including a preliminary step of DDT to relax the whole chromatin structure and allow access to all ‘nicks’. They have also added a viability stain so that DNA damage is measured only in live sperm. This has eliminated a previous inaccuracy of measuring damage (often at high levels) in dead cells. The TUNEL has major potential but robust clinical thresholds have yet to be established.

4. The sperm chromatin dispersion (Halo) test

The Halo test is a ‘cheap and convenient’ kit form of sperm DNA testing. It is a simple and inexpensive assay, available in fertility labs for in house use. Unlike all the other tests, it measures the absence of damage rather than the damaged DNA in sperm. One limitation of the assay is that its low-density nucleoids are relatively faint, with less contrasting images. To date, correlations have been observed between DNA and other sperm parameters, although few correlations between sperm DNA damage and ART outcomes have been established with the Halo test, even in large studies.

5. The Comet assay

The comet assay is a second generation sperm DNA test. Unlike the other three tests, it quantifies the actual amount of DNA damage per sperm. As the mass of DNA fragments stream out from the head of unbroken DNA, they resemble a ‘heavenly comet’ tail, hence the name of the assay. One major advantage of this assay is that it uses only 5000 sperm, so is suitable for the assessment of small samples left over from clinical use, or for samples where only a few sperm are available. The Comet assay can measure both single and double strand breaks, and with an additional step can measure even altered bases. This is useful, because we do not yet know which types of DNA damage are most deleterious to male fertility. The Comet is sensitive, repeatable and capable of detecting damage in every sperm (even those of fertile donors). Since 2010, clinical thresholds for the diagnosis of male infertility and the prediction of successful IVF have been established.

5.1. Unexplained infertility is unexplained no more

As we all know, unexplained infertility is a very unsatisfactory diagnosis for couple and clinic alike. In our latest study we have shown that 80% of couples diagnosed with idiopathic infertility have sperm DNA damage (>25% damage per sperm). This suggests that sperm DNA damage is the cause of infertility in a substantial number of men if we compare these levels of damage we reported in sperm of donor men with proven fertility (15). We also reported that 40% of these couples had such high sperm DNA damage (>50%) that IVF had very poor success for them. Couples with idiopathic infertility had lower live birth rates following IVF (15%) compared with couples undergoing IVF (20%) following the detection of a female problem. This finding is also reflected in disappointedly low effectiveness of the IVF treatment when measured as the cumulative incidence of live delivery after commencing IVF treatment. Previously we would have expected these couples to have high success rates since we could detect no anomalies but we now know this is a mis-diagnosis. Offering them IVF or in some cases (IUI) without DNA testing can lead to treatments with very low chances of success. From the clinic’s viewpoint, using IVF for these couples is a poor choice too as it reduces their overall IVF success rates.

5.2. The benefits of sperm DNA testing

For all couples having IVF, after diagnosis with a female factor, sperm DNA fragmentation also has a close inverse relationship with live birth rates. Our latest results (15) were based on dividing couples into groups depending on the severity of their sperm DNA damage. Those with sperm DNA fragmentation (<25%) had live births of 33% following IVF treatment. In contrast, couples with sperm DNA fragmentation (>50%) had a much lower live birth rates of 13% following IVF treatment.

If we were to incorporate this new information into routine clinical care, we could direct these patients straight to ICSI treatment thus avoiding loss of valuable biological time, cost of failed cycles and heartache after repeatedly unsuccessful cycles of IVF treatment.

Further compelling reasons for testing sperm DNA come from its strong associations with miscarriage. A systematic review and meta-analysis (16) of 16 cohort studies (2969 couples), 14 of which were prospective studies which examined the effect of sperm DNA damage on miscarriage rates was performed. We used the terms ‘DNA damage’ or ‘DNA fragmentation’ combined with ‘miscarriage’, ‘abortion’ or ‘pregnancy’ to generate a set of relevant citations. Sub-group analyses were performed by the type of DNA damage test, whether the sperm examined were prepared or raw ejaculate and IVF or ICSI treatment. The meta-analysis showed a significant increase in miscarriage in patients with high DNA damage compared with those with low DNA damage (Risk Ratio (RR) = 2.16 [1.54, 3.03], P < 0.00001).

5.3. A fresh look at the ‘evidence’ against Sperm DNA damage testing

The meta- analyses of Zini and Sigman (19) and of Collins et al. (5) were the first to bring all the sperm DNA data together and highlight the substantial body of work. However, we must view their conclusions with caution due to the significant heterogeneity of different assays, different female ages, some sperm from raw semen, some from prepared sperm, different ART endpoints and different thresholds for clinical significance. The primary objective of the ESHRE position paper in 2009 was not to support or refute clinical DNA testing. It was written as an overview of the maturational vulnerabilities of sperm DNA and a mechanistic look at DNA damage and repair. The section on clinical testing was less than 10% of the content. In addition, as with the meta- analysis by Zini and Sigman (19), it did not include Comet data. The objective of the ‘Cochrane’ review by Van Rumste et al. (17) was to investigate if live birth rates were better with ICSI than IVF in couples with non male sub-fertility. The review began with ten randomized controlled trials but all but one study were excluded for design reasons. The one study as we know was from Bhattacharya et al., and published in The Lancet in 2001 (4). However, the numbers of couples included in this one study are relatively small (n = 224 in IVF group, n = 211 in ICSI group). Even this study did not give live birth rates or miscarriage rates. The couples were identified as having non-male sub-fertility at time of study (2001) by semen parameters that are now viewed as neither predictive of diagnosis of male infertility nor useful in predicting ART outcome. As with all Cochrane reviews it concluded that further studies are needed.

The American Society of Reproductive Medicine (ASRM)(2) has recently released a position paper for consultation (2013) (3). In my opinion, this paper presents a negatively biased and unbalanced overview. It dismisses the findings of around 100 papers in high impact journals over the last 30 years (11) as ‘insufficient evidence’ and turns the range of different sperm DNA tests measuring different aspects of DNA damage into a weakness rather than accepting it as the strength it is. My specific objections include the ASRM requirement of Level 1 evidence of quality from randomized controlled trials prior to clinical use. This is in stark contrast to the approach adopted to ICSI in 1995, when it became a routine publically funded fertility treatment on a global scale without any human trials at all. Further, I would direct you to the paper by (9) followed by the letter by Richard Legro in Fertility and Sterility in December 2012 (12) commenting on the quality of RCTs over 2006–2011 in five leading human reproduction journals and pointing out that incomplete outcome data and inadequate allocation concealment led to bias in almost 50% of them.

In terms of ASRM Level 11 requirements, the sperm DNA test designed in our lab; the SpermComet; conforms to all of them. These data result from studies performed on large numbers of over 500 couples. These couples were consecutive cases and were controlled for female factors. The primary endpoints were live birth rates. However, despite numerous reviews showing its serious limitations of semen analysis and evidence of the stronger repeatability, sensitivity and specificity of sperm DNA damage testing, ASRM still supports the continued use of semen analysis alone for diagnosis. Further, the level of precision that ASRM requires, can never come from one test. Fertilization is a multi-factorial process and a successful ART outcome depends on many other traits of sperm quality and function, as well as the influences of the oocyte, uterine receptivity and maternal immune system competence. Finally, the ASRM document, having begun by criticizing DNA testing as measuring different aspects of DNA damage and therefore being non-uniform, then criticized DNA testing for being non specific ‘for not providing an indication of specific DNA sequences that may be affected’. As no one yet knows what aspects of DNA damage at large, nor any specific sequences that are responsible for ‘male infertility’, neither of these opposing criticisms are based on sound science.

5.4. Reasons why sperm with poor DNA are successful in ICSI

One question that has exercised my mind much upon analyzing the data is ‘Why do sperm with DNA damage not reduce success following ICSI?’

I have four hypotheses (all based on sound studies) to explain this:

Firstly, up to 30% of women having ICSI have no detectable problems. They may be fertile and their oocytes may have more capacity to repair DNA damage even if the injected sperm is of poor quality. This is supported by the findings of Meseguer et al. (13), where high quality oocytes from donors offset the negative impact of sperm DNA damage on pregnancy. Further, the study of Devroey et al. (7), shows that significantly fewer good quality embryos were available for transfer from women more than 40 years of age compared to the younger group, reflecting better DNA repair capacity of oocytes from young women. This is relevant in that women undergoing ICSI are often younger than those undergoing IVF as their cause of infertility has been diagnosed earlier and they have not spent time undergoing failed intrauterine insemination or IVF before embarking on a cycle of ICSI. Secondly, in ICSI, the gametes are not subjected to prolonged culture so the sperm may have less damage than those exposed to culture media overnight, as in IVF procedures. The recent major study from Dumoulin et al. (8) shows that even the birth weight of IVF babies can be markedly influenced by minor differences in culture conditions. In contrast to IVF, ICSI sperm are injected into the optimal environment of the oocyte within a few hours of ejaculation. This may protect them from laboratory induced damage. Thirdly, much sperm DNA damage is caused by oxidative stress (1) and so these sperm are producing reactive oxygen species. If they are used in IVF, the oocyte may be exposed to oxidative assault during the overnight incubation from these ∼0.5 million sperm. In ICSI, the oocyte is protected from this attack and can use its energies to repair the damage in the sperm immediately following fertilization. Finally, there is now evidence that embryos created from sperm with high DNA damage are associated with early pregnancy loss (reviewed by Robinson et al. (16) so ICSI success rates are sometimes affected adversely by sperm DNA damage, but at a later stage.

5.5. Limitations of sperm DNA testing

The major limitation of testing for sperm DNA damage is that the assay renders the tested sperm unsuitable for clinical purpose. In an effort to overcome this problem, a number of non-invasive tests have been developed and their correlation with DNA damage assessed. These novel test include Birefringence, Intracytoplasmic morphologically selected sperm injection (IMSI) and Hyaluronic acid-selection of sperm for ICSI. If these tests can help embryologists choose sperm with low DNA damage for ART, a major step forward in sperm selection will be achieved, but presently this is not the case.

5.6. Why wait? The benefits for clinics and couples

Couples will avoid the loss of valuable biological time, the cost of failed cycles and the heartache of repeatedly unsuccessful cycles of IVF treatment. Unexplained couples will get a diagnosis and thus directs to the best treatment for them. Happier, better informed couples will spread the word of their clinic’s success.

Clinics will have improved IVF success rates, a scientific rationale for using ICSI and additional revenue from appropriate male fertility testing. Their greater success rates will help them retain their patient bases (with couples attending for their next child!).

Alas, although some of these novel biomarkers (particularly sperm DNA testing) have increasingly robust data to support them, there is still a reluctance to incorporate them into routine clinical care. While this inertia continues and our traditional tests prevail, it seems unlikely that success rates in the treatment of male infertility will improve and success rates will be doomed to mediocrity.

References

  1. R.J. Aitken, G.N. De Iuliis Origins and consequences of DNA damage in male germ cells Reprod Biomed Online, 14 (6) (2007), pp. 727-733 ArticleDownload PDFView Record in ScopusGoogle Scholar
  2. American Society for Reproductive Medicine Intracytoplasmic sperm injection (ICSI) for non- male factor infertility- a committee opinion Fertil Steril, 98 (2012), pp. 0015-0282 Google Scholar
  3. American Society for Reproductive Medicine. The Clinical Utility of Sperm DNA testing-a guideline, under consultation. 2013. Google Scholar
  4. S. Bhattacharya, M.P. Hamilton, M. Shaaban, Y. Khalaf, M. Seddler, T. Ghobara, P. Braude, R. Kennedy, A. Rutherford, G. Hartshorne, A. Templeton Conventional in-vitro fertilisation versus intracytoplasmic sperm injection for the treatment of non-malefactor infertility: a randomised controlled trialLancet, 357 (2001), pp. 2075-2079 ArticleDownload PDFView Record in ScopusGoogle Scholar
  5. J.A. Collins, K.T. Barnhart, P.N. SchlegelDo sperm DNA integrity tests predict pregnancy with in vitro fertilization? Fertil Steril, 89 (4) (2008), pp. 823-831 ArticleDownload PDFView Record in ScopusGoogle Scholar
  6. J. DeMouzon, V. Goossens, S. Bhattacharya, J.A. Castilla, A.P. Ferraretti, V. Korsak, M. Kupka, K.G.Nygren, A. Nyboe Andersen Consortium the European IVF-monitoring (EIM). Assisted reproductive technology in Europe, 2006: results generated from European registers by ESHRE Hum Reprod, 25 (2006), pp. 1851-1862View Record in ScopusGoogle Scholar
  7. P. Devroey, H. Godoy, J. Smitz, M. Camus, H. Tournaye, M.P. Derde, A. VanSteirteghem Female age predicts embryonic implantation after ICSI: A case-controlled study Hum Reprod, 1 (6) (1996), pp. 1324-1327CrossRefView Record in ScopusGoogle Scholar
  8. J.C. Dumoulin, J.A. Land, A.P. Van Montfoort, E.C. Nelissen, E. Coonen, J.G. Derhaag, I.L. Schreurs, G.A. Dunselman, Kester, J.P. Geraedts, J.L. Evers Effect of in vitro culture of human embryos on birthweight of newborns Hum Reprod, 25 (2010), pp. 605-612CrossRefView Record in ScopusGoogle Scholar
  9. Riestra Glujovsky Demián; Bárbara, Coscia Andrea, Boggino Carolina, et al.Assessment of research quality in major infertility journalsFertil Steril, 98 (6) (2012), pp. 1539-1543 Google Scholar
  10. National Cooperative Reproductive Medicine NetworkD.S. Guzick, J.W. Overstreet, P. Factor-Litvak, C.K. Brazil, S.T. Nakajima, C. Coutifaris, S.A. Carson, P.Cisneros, M.P. Steinkampf, J.A. Hill, D. Xu, D.L. Vogel Sperm morphology, motility, and concentration in fertile and infertile men N Engl J Med, 345 (19) (2001), pp. 1388-1393 CrossRefView Record in ScopusGoogle Scholar
  11. E.M. Lewis Sheena, R. John Aitken, Conner Sarah J, Iuliis Geoffry De, Evenson Donald P, Henkel Ralph, Giwercman Aleksander, Gharagozloo Parviz The impact of sperm DNA damage in assisted conception and beyond: Recent advances in diagnosis and treatment Reprod Biomed (2013)[accepted for publication] Google Scholar
  12. R.S. Legro Quovadis randomized controlled trials in infertility?Fertil Steril, 98 (2012), p. 1350 ArticleDownload PDFView Record in ScopusGoogle Scholar
  13. M. Meseguer, R. Santiso, N. Garrido, S. Garcıa-Herrero, J. Remohı, J.L. Fernandez Effect of sperm DNA fragmentation on pregnancy outcome depends on oocyte quality Fertil Steril, 95 (2011), pp. 124-128 ArticleDownload PDFView Record in ScopusGoogle Scholar
  14. L.A. Mitchell, G.N. De Iuliis, R.J. Aitken The TUNEL assay consistently underestimates DNA damage in human spermatozoa and is influenced by DNA compaction and cell vitality: development of an improved methodology Int J Androl, 34 (2011), pp. 2-13 CrossRefView Record in ScopusGoogle Scholar
  15. L.I. Simon, M. Proutski, D. Stevenson, J. Jennings, D. McManus, S.E.M. Lutton Lewis Sperm DNA damage has negative association with live birth rates after IVF Reprod Biomed Online, 26 (2013), pp. 68-78 ArticleDownload PDFView Record in ScopusGoogle Scholar
  16. L. Robinson, I.D. Gallos, S.J. Conner, M. Rajkhowa, D. Miller, S. Lewis, J. Kirkman-Brown, A.Coomarasamy The effect of sperm DNA fragmentation on miscarriage rates: a systematic review and meta-analysis Hum Reprod, 27 (10) (2012), pp. 2908-2917 CrossRefView Record in ScopusGoogle Scholar
  17. M.M.E. Van Rumste, J.L.H. Evers, C.M. Farquhar Intra-cytoplasmic sperm injection versus conventional techniques for oocyte insemination during in vitro fertilisation in patients with non-male subfertility Cochrane database Syst Rev (Online), 2 (2003), p. CD001301 View Record in ScopusGoogle Scholar
  18. World Health Organization. WHO laboratory manual for the examination and processing of human semen. 5th ed. Department of Reproductive Health and Research, WHO; 2010 Google Scholar
  19. A. Zini, M. Sigman Are tests of sperm DNA damage clinically useful? Prosand cons J Androl, 30 (2009), pp. 219-229CrossRefView Record in ScopusGoogle Scholar

https://doi.org/10.1016/j.mefs.2013.01.010
